FEATURES

• Ergonomic design keeps retractable units elevated on the back to reduce fatigue and maximize productivity
• Energy absorber cover includes comprehensive fall clearance charts and tables
• Internal mechanism design minimizes unintentional lockups to keep you moving freely and productively
• Suitable for below D-ring tie-off up to five feet and leading edge exposures and hazards, including steel and precast concrete
• Rated for workers weighing up to 310 pounds, including clothes, tools, gear, etc.
• Complies with ANSI Z359.14-2021 Class 2 SRL-P

MATERIAL SPECIFICATIONS

• Cable: 3/16" galvanized steel; 3,600 lb min. static strength
• Energy Absorber: Polyester tear-away
• Anchorage Connector: Plated alloy steel; 5,000 lb min. static strength with 3,600 lb gate strength
• Dorsal Connector: Aluminum alloy; 3,600 lb min.

PERFORMANCE SPECIFICATIONS

• Static Strength: 3,600 lb min.
• ANSI SRL Class/Type: Class 2 SRL-P
• Avg. Arrest Force: 1,350 lb max.
• Max. Arrest Force: 1,800 lb
• Max. Arrest Distance: 42"
• ANSI User Capacity: 130 to 310 lb max.
• OSHA User Capacity: 130 to 310 lb max.

DOWNLOADS

• Instruction Manual
• Declaration of Conformity (ANSI)
• Sell Sheet/Brochure
• CTX™ Flyer
• Spec Sheet

COMPLIANT WITH:

• OSHA 1926.502 and 1910.66
• ANSI Z359.14-2021
